China Wholesale ADVU sERIES PNEUMATIC CYLINDER Filling Machine Injection Molding Machine PET Bottle Blow Molding Machine
Specification
| Bore size(mm) | 12 | 16 | 20 | 25 | 32 | 40 | 50 | 63 | 80 | 100 |
| Action | Double acting,single acting | |||||||||
| Fluid | Air | |||||||||
| Operating pressure range | 0.12~1.0Mpa | |||||||||
| Ambient and fluid temperature | -20~80ºC(No freezing) | |||||||||
| Port size |
M5 |
G1/8 |
G1/4 |
|||||||
| Cushion | Rubber cushion | |||||||||
Bore size: 16mm 20mm 25mm 32mm 40mm 50mm 63mm 80mm
1.We can offer ADVU pneumatic cylinder and Air cylinder kits,also have DNC Series and DSNU Series
2.Bore 16mm 20mm 25mm 32mm 40mm 50mm 63mm 80mm ADVU Air Pneumatic Cylinder available.
3. Carry out international standard and adopt aluminum alloy tube pneumatic cylinder body.The compact Pneumatic cylinder is a cylindrical metal part that guides the piston rod to reciprocate in a straight line.The compact pneumatic cylinder parts include: pneumatic cylinder aluminum extrusion tube, end cover, piston, piston rod and seal kits.
Characteristic
1) This series of pneumatic cylinder conforms to: FESTO standard
2) Compact pneumatic cylinder has the advantages of compact structure, light weight, and small space occupation.
3) We can offer different kinds of mounting style according to FESTO standard, like Foot mounting, Front flange mounting, Rear-flange mounting, and so on.
4) Different thread type can be offered according to customers' requirements, e.g.:BSP, NPT etc.
Feautres
Pneumatics is the technology that uses compressed air to operate different mechanisms. In the industrial sector it is used in multiple processes and applications.The pressure energy of compressed air is converted into mechanical energy, and the driving mechanism makes linear reciprocating motion, swinging and rotating motion.
FAQ
Q1:What is the pneumatic cylinder?
A:China Pneumatic Cylinder refers to the assembly of the pneumatic cylinder including the Air Cylinders Tube(6063 Cylinder Tube) and piston rod, including the Pneumatic cylinder end cover, pneumatic cylinder piston, sealing ring, etc.
Q2:What is the SDA model?
A: The SDA is Airtac standard model. It have double action, single action extrusion, single action drawing-in type, double- shalf double action type, double-shalf and adjustable stroke type for you choose.
Q3:What is the standard of your air cylinder?
A:Our pneumatic cylinder are produced in strict accordance with the standard of the international. In order to avoid air leakage, the size of the end cover must match the size of the pneumatic cylinder.
For example, our standard for SI pneumatic cylinders is ISO6431; our standard for DNC pneumatic cylinders is VDMA24562.
Q4: What is the material of pneumatic cylinder?
A:The cylinder barrel of the cylinder is made of aluminum alloy cylinder barrel.The Pneumatic Cylinder Assembly Kits of seal kit is made by NBR.
